How does solar battery storage work?

A simple grid connected solar system does not need batteries to function.

If you think about it – it actually uses the grid as an infinitely large battery. If the solar panels on your roof are creating more power than is needed by your home, then the excess goes into the grid:

Exporting surplus solar electricity

 My home solar energy system is exporting surplus solar to the grid (a screen grab from the Tesla monitoring app)

Later, if your panels can’t produce enough electricity, energy is drawn from the grid to make up the difference:

Importing grid electricity

My home solar power system importing grid electricity because I’m not generating enough solar.

Three reasons you may want to add batteries to a grid connected solar system

Reason to add a battery #1) You don’t want to export all your surplus solar energy – you’d like to store it in a battery instead:

battery charging from solar panels

If you add a battery you can charge it with your surplus solar energy.

Storing excess solar energy in your battery to use later makes intuitive sense. But at the time of writing (March 2020) it doesn’t make economic sense for most Australians. That’s because unsubsidised batteries are still very expensive and the payments you get for simply exporting to the grid can be reasonably generous outside of WA. To see how much (or how little) a battery will save you you can use our solar and battery calculator. Uniquely, it shows you the solar and battery savings separately for total transparency (all other solar calculators I’ve seen mush the solar and battery savings together). If you already have solar installed but want to calculate the savings of adding a battery to your system, you can use our “Add a battery” calculator.

Reason to add a battery #2) You want to have backup power available if the grid goes down.

A regular solar power system can’t power your home when the grid goes down, because – as we’ve just seen – the grid is required to either:

a) absorb surplus solar energy or

b) top-up insufficient solar.

But a good battery system will allow you to power some or all of your home if the grid goes down.

Reason to add a battery #3) You want to indulge in some sneaky electricity arbitrage (if you are on a time-of-use tariff).

e.g. charge the battery with cheap off-peak electricity and use it in peak times.

Sounds great in theory doesn’t it? Unfortunately I’ve crunched the numbers and it just makes no economic sense to do this with retail electricity prices, so I won’t waste your time getting into it.

A word of warning: Option 1 (batteries for storing solar energy to use when the sun isn’t shining) and Option 2 (batteries for use when the grid goes down) are not inseparable. Some battery systems do not offer backup when the grid goes down. So if backup is important to you, ask your installer for it, and have a conversation about which circuits in your home must be backed up.

Why don’t all battery systems offer backup? Because leaving out backup makes the system cheaper and quicker to install.

The rest of this article will give explain why battery systems with backup are different and more expensive than systems without backup.

Things will start getting a little geeky, so if you’d just like to learn more about batteries generally instead, head on over to my solar battery storage home page. It contains some good summary information and links to everything I think you need to know.

Let’s get started!

Solar battery storage system without backup (AKA hybrid solar without backup)

hybrid solar without backupThis is the simplest and cheapest type of solar plus storage system available. Electrically, it treats the battery pack like another solar panel array. So, the battery pack plugs straight into a spare input on your solar inverter.

All that is required for this battery integration is:

a) A battery pack with high voltage DC output and integrated charger.

b) A separate battery inverter or a hybrid solar + battery inverter. Both options will need talk to the battery’s management system (BMS) so that the battery is not overcharged.

c) A way to know how much electricity the  home is currently importing or exporting – so the battery knows when it is a good time to charge (i.e. when there is spare solar energy) and when it is a good time to discharge (i.e. when there is not enough solar to power the nome).

As you can see – this should make for a relatively quick, cheap and easy installation.

A solar battery storage system with backup (AKA hybrid solar with backup)

This type of system is more expensive. I’ll go through how they work to give you an understanding of why that is so.

There are 2 main ways to skin this cat: AC coupling and DC coupling.

AC coupled systems use 230V AC to charge the batteries. This is the most common way to retrofit batteries to an existing solar system, because all solar inverters output output 230V (including microinverters).

An AC coupled system will generally have 2 inverters, the existing solar inverter, and a battery inverter). The inverter charger controls the charging and discharging of the battery. It also monitors the grid connection, and if grid power fails it switches almost instantly to battery (+solar) power so your lights won’t go out. The battery inverter may be a separate box, or it may be included in the battery box – the latter is known as an “all-in-one” system.

As well as an extra inverter, you may need to rewire your switchboard to separate out ‘essential circuits’ and ‘non-essential circuits’.

The typical Aussie home can pull a lot of power. If your A/C is going, your oven is on, and someone puts the kettle on for nice cuppa, the peak draw could easily be 7-8kW. That will instantly overload all but the biggest, most expensive battery packs. For example the Tesla Powerwall is rated at a peak power of 7kW, but only 5kW continuous. Even if it does not overload, you would quickly drain the battery.

For this reason, battery backup systems usually don’t try to backup the entire house. The most important appliances such as the fridge and the lights are generally wired into a separate ‘essential circuit’, and the stuff you can live without stays on the ‘non-essential’ circuit.

This keeps the battery pack cost down and lets your house run for a lot longer without the grid.

This block diagrams that show how all this works:

Essential and non-essential circuits

If your home can pull more power than your battery can provide, then you should have essential and non-essential circuits. The essential circuits are disconnected when the system isolates from the grid. The essential circuits remain backed up by your solar power system and battery.

As you can see, it is more involved than the design without backup. Here are the extra costs:

1) A special battery inverter that safely switches to solar and batteries if the grid goes down (or an all-in-one battery system that is more expensive than other storage solutions).

2) Modification of switchboard wiring to have a backed up ‘Essential AC Loads’ and a non backed up ‘Non-essential AC Loads’ circuit. Often the essential loads are put in a new switchboard altogether.

3) Enough batteries to cope with both the peak power of your chosen loads, and with enough energy storage to run as long as you specify without the grid. The typical Aussie home uses about 20kWh per day of electricity, so they’d probably need 7 kWh of storage at a minimum to last them through a blackout of more than a few hours. 7 kWh of lithium-ion storage will cost about $7,000-$8,000 installed unless you can get a battery rebate.

Technical note: Imagine the system in the diagram above running without the grid (i.e. the switch is open). What happens when the batteries are full and the solar is generating more electricity than the house needs? Where does the excess solar electricity go? There is nowhere for it to go. Solar battery systems handle this problem one of two ways:

1) Totally disable the solar panels when the grid is disconnected.

2) Throttle the solar panels to produce no more power than can be used.

Some systems choose option 1. The problem there is that the solar panels cannot then charge the batteries when the grid is down. So your batteries will not get recharged in a blackout and may run flat before the grid comes back. Don’t buy a battery system that does this.

The better systems choose to throttle the solar down. They can do this in one of two ways.

a) They can talk to the solar inverter and ask it nicely. To do this the battery inverter needs to be compatible with the solar inverter. An example of this is a Fronius solar inverter and a Selectronic battery inverter.

b) The battery inverter can shift the frequency of the 230 VAC enough to shut down the solar inverter when required. All solar inverters are programmed to shut down at a certain frequency – so this works for any solar inverter.  An example of this is the Tesla Powerwall.

One last thing – let’s talk about the elephant in the room. Namely – if you are going to get batteries why all this talk about being grid connected? Why not simply go off grid altogether? Read on.


>> Next: Should you use your batteries to go off-grid? >>
